Service Bridges

Service Bridges allow you to configure proxy endpoints that connect your project to external APIs. They enable modules and the platform to interact with external services through a managed, authenticated gateway.

Service Bridges grid showing configured bridges with names, target URLs, and status

What are Service Bridges?

A service bridge creates a proxy endpoint within the Kodexa platform that forwards requests to an external API. This provides:

Centralized authentication — API credentials are managed as organization secrets, not embedded in modules. The platform supports automatic OAuth token management.
Request routing — Modules reference a bridge endpoint rather than external URLs directly
Caching — Responses can be cached per-endpoint with configurable TTL
Request/response transformation — JavaScript hooks can modify requests before sending and responses before returning
Monitoring — All requests through bridges are logged and can be monitored

Managing Service Bridges

Creating a Service Bridge

Click Add Service Bridge

Open the creation form from the Service Bridges page.

Configure Endpoint

Set the bridge name, target URL, authentication method, and any required headers.

Test Connection

Verify that the bridge can reach the external API.

Save

The bridge endpoint becomes available for use in your project’s modules and pipelines.

Service Bridge creation form showing name, target URL, and authentication configuration

Service bridges use organization secrets for authentication credentials. Make sure the required secrets are configured before creating a bridge that needs them.

YAML Configuration Reference

Service bridges are defined in YAML and deployed with kdx sync. Here is the full structure:

type: serviceBridge
slug: my-bridge
orgSlug: my-org
name: "My External API"
template: false
publicAccess: false

metadata:
  baseUrl: "https://api.example.com"       # Supports ${secrets.X} interpolation
  description: "Connects to the example API"
  provider: "Example Corp"
  agentCallable: false                     # Allow agents to call this bridge

  # Authentication (see below for details)
  auth:
    type: oauth2_client_credentials
    tokenUrl: "/v1/auth/token"              # Relative to baseUrl, or absolute
    clientId: "${secrets.MY_CLIENT_ID}"
    clientSecret: "${secrets.MY_CLIENT_SECRET}"

  defaultHeaders:
    - name: "Content-Type"
      value: "application/json"

  endpoints:
    - name: "get-data"
      description: "Fetch data from the API"
      path: "/v1/data"
      method: GET
      cacheEnabled: true
      cacheTtlSeconds: 300

Secret References

Use ${secrets.SECRET_NAME} to reference organization secrets in your bridge configuration. The platform resolves these at request time. This works in:

baseUrl
auth.clientId, auth.clientSecret, auth.tokenUrl
Header values

metadata:
  baseUrl: "${secrets.MY_API_BASE_URL}"
  auth:
    clientId: "${secrets.MY_CLIENT_ID}"
    clientSecret: "${secrets.MY_CLIENT_SECRET}"

secretRef on a header is not supported. A header configured with secretRef is rejected with a 400 naming the header, rather than being sent upstream with an empty value — which is what used to happen, producing a 401 from the external API with nothing pointing at the real cause. Put the secret in the header value as ${secrets.NAME} under defaultHeaders instead.

Agent Access

By default a bridge is callable by people and by the project’s own scripts, forms, and Activity steps. Set agentCallable to let automated agents call it as well:

metadata:
  agentCallable: true

Field	Type	Default	Description
`agentCallable`	boolean	`false`	Allows agents to call this bridge’s endpoints through the proxy. Absent or `false` means deny.

Two conditions are both required before an agent may call a bridge:

agentCallable is true — the Callable by agents toggle under Agent access on the bridge’s General tab, or the field above in YAML.
The bridge is bound to the agent’s project as a project resource.

Agents see only the bridges that satisfy both conditions, and cannot change the flag or the project binding themselves. A call that fails either check is refused with 403. Credentials stay on the platform and are never shown to the agent. The same two checks admit both activity-plan AGENT steps and module or task executions running as the project’s assistant, so a module can call the bridges bound to its own project. Any caller whose project cannot be resolved is denied.

Egress Restrictions

A bridge must target a publicly resolvable host. A destination that resolves to a loopback, private, link-local, or cloud-metadata address is refused before any connection is made, as are hostnames that are platform-internal by name (localhost and the platform’s own internal domains). Every hop of a redirect chain is re-checked rather than followed blindly, and the resolved address is pinned for the call. A refused call through the proxy returns 400 with service bridge egress denied and the reason; a refused BRIDGE_CALL Activity step fails with the same reason.

The check covers auth.tokenUrl as well as endpoint paths, so an OAuth token endpoint must also be publicly resolvable.

Self-hosted deployments that must reach an internal mock or test service can set BRIDGE_EGRESS_PRIVATE_HOST_ALLOWLIST — a comma-separated list of exact hostnames — in the environment of both the API and the orchestrator. Matching is exact and case-insensitive, with no wildcards and no CIDR ranges; a redirect from an exempted host into any other private destination is still refused; and an active allowlist is logged as a warning at startup. It is intended for development and test environments only.

Authentication

OAuth 2.0 Client Credentials

The platform can automatically manage OAuth 2.0 client credentials token lifecycle — acquiring tokens, caching them, and refreshing on expiry. This eliminates the need for external token rotation.

metadata:
  auth:
    type: oauth2_client_credentials
    tokenUrl: "/v1/auth/token"
    clientId: "${secrets.CLIENT_ID}"
    clientSecret: "${secrets.CLIENT_SECRET}"

The platform will:

Fetch a token from the token endpoint on the first request
Cache the token until near expiry
Automatically refresh when the token expires
Retry once with a fresh token if the upstream API returns 401 or 403

Standard vs Custom Token Requests

Most OAuth providers use the standard form-encoded format (RFC 6749). The platform uses this by default:

POST /token
Content-Type: application/x-www-form-urlencoded

grant_type=client_credentials&client_id=...&client_secret=...

If your token endpoint expects a custom JSON body, use requestFormat: custom:

metadata:
  auth:
    type: oauth2_client_credentials
    tokenUrl: "/v1/auth/token"
    clientId: "${secrets.CLIENT_ID}"
    clientSecret: "${secrets.CLIENT_SECRET}"
    requestFormat: custom
    requestBody:
      grantType: "client_credentials"
      clientId: "${auth.clientId}"
      clientSecret: "${auth.clientSecret}"

The ${auth.clientId} and ${auth.clientSecret} placeholders in requestBody are substituted with the resolved values from the auth block.

Custom Response Mapping

If the token endpoint returns non-standard field names, use responseMapping:

metadata:
  auth:
    responseMapping:
      accessToken: "accessToken"     # Default: "access_token"
      expiresIn: "expiresIn"         # Default: "expires_in"

Full Auth Configuration Reference

Field	Type	Default	Description
`type`	string	required	Authentication type. Currently `oauth2_client_credentials`.
`tokenUrl`	string	required	Token endpoint URL. Relative paths are resolved against `baseUrl`.
`clientId`	string	required	OAuth client ID. Supports `${secrets.X}`.
`clientSecret`	string	required	OAuth client secret. Supports `${secrets.X}`.
`requestFormat`	string	`"standard"`	`"standard"` (form-encoded) or `"custom"` (JSON body).
`requestBody`	object	—	Custom JSON body template when `requestFormat` is `"custom"`.
`responseMapping`	object	—	Maps non-standard token response field names.
`tokenCacheBufferSeconds`	integer	`60`	Seconds before expiry to refresh the token.
`headerName`	string	`"Authorization"`	HTTP header for the token.
`headerPrefix`	string	`"Bearer"`	Prefix prepended to the token value.

Static API Key / Bearer Token

For APIs that use a static API key or pre-generated token, set it directly in headers using a secret reference in the header’s value:

metadata:
  defaultHeaders:
    - name: "Authorization"
      value: "Bearer ${secrets.MY_API_TOKEN}"
    - name: "X-API-Key"
      value: "${secrets.MY_API_KEY}"

This is the supported placement for a header credential. ${secrets.NAME} in a header value is resolved on the platform immediately before the request goes out — on defaultHeaders and on endpoint-level headers alike — and a header configured with secretRef instead is rejected with a 400 naming the header.

Endpoints

Each endpoint defines a path on the external API that the bridge exposes.

endpoints:
  - name: "get-users"                  # Used in serviceBridge.call()
    description: "List all users"
    path: "/v1/users"                  # Appended to baseUrl
    method: GET
    cacheEnabled: true                 # Cache GET responses
    cacheTtlSeconds: 600               # Cache for 10 minutes

The name is matched exactly. Calling a name the bridge does not define returns an error listing the endpoint names it does define, so a misspelling is reported as one — it is never resolved to another endpoint.

Request and Response Schemas

Optionally document the expected request and response shapes using JSON Schema:

endpoints:
  - name: "create-user"
    path: "/v1/users"
    method: POST
    requestSchema:
      type: object
      properties:
        name:
          type: string
        email:
          type: string
      required:
        - name
        - email
    responseSchema:
      type: object
      properties:
        id:
          type: string
        name:
          type: string

requestSchema.required is also a runtime guard. While any required field is absent, the proxy returns an empty [] result without calling the external API — the behaviour that keeps a dependent dropdown showing no options until its prerequisite field has been filled in. A required field counts as supplied when it appears in either the JSON body or the query string, so a GET-style endpoint that carries its parameters in the URL reaches the external service instead of short-circuiting. Presence is what is tested, not value: an empty string, 0, or false all satisfy a required field, while a missing key or an explicit null does not.

Script Hooks

Endpoints support JavaScript hooks for request/response transformation:

Hook	Runs	Input	Can Return
`initScript`	Once per request (when no client context)	`{headers, config}`	`{headers, context}`
`preSendScript`	Before each outbound call	`{headers, body, context}`	`{headers, body}`
`postReplyScript`	After each response	`{statusCode, body}`	`{body}`

endpoints:
  - name: "lookup"
    path: "/v1/lookup"
    method: POST
    postReplyScript: |
      var data = JSON.parse(input.body);
      var options = data.map(function(item) {
        return { label: item.name, value: item.code };
      });
      return { body: JSON.stringify(options) };

Using Service Bridges from Script Steps

Service bridges that are added as project resources can be called directly from script steps in plan workflows. Scripts can discover available bridges with serviceBridge.list() and make HTTP requests with serviceBridge.call().

// List all bridges available to this project
var bridges = serviceBridge.list();

// Call an endpoint
var result = serviceBridge.call("my-bridge", "get-data");
log("info", "Response: " + JSON.stringify(result));

return { action: "done" };

See the Script Steps guide for full documentation on using service bridges from scripts.

Using Service Bridges from Data Forms

Data forms can call service bridge endpoints both declaratively and from scripts:

Declarative (Selection Options)

In taxonomy definitions, use selectionOptionFormula to populate dropdowns:

selectionOptionFormula: 'serviceBridgeCall("my-org/my-bridge", "get-options")'

With parameters:

selectionOptionFormula: 'serviceBridgeCall("my-org/my-bridge", "get-options", "paramName", {fieldPath})'

From Data Form Scripts

var result = await bridge.serviceBridge.call(
  'my-org/my-bridge',
  'get-data',
  { id: fv['orders/code'] }
);

Loading Shared Modules in Bridge Scripts

Service bridge endpoint scripts can load shared JavaScript modules using the Module Refs picker in the endpoint configuration. Pre-loaded modules’ functions and variables are available in global scope within your bridge script, letting you reuse request/response transformation logic across endpoints. Select one or more JavaScript modules from your organization. They are fetched and executed in order before your bridge script runs.

// Assuming "my-org/transform-utils" is loaded via Module Refs
var payload = transformRequest(request);
var result = serviceBridge.call("external-api", "submit", payload);
return formatResponse(result);
